Characteristics

Proprietary formaldehyde-free glass composite construction
Monolithic appearance – large format panels, semi-concealed suspension, nominal ¼" reveals
Convenient swing-down access to the plenum
Trims are engineered for fast installation of Techstyle®
Lighting and diffuser integration
Enhanced soiling resistance and clean-ability
Formaldehyde free
Class A Fire Rating, per ASTM E84
GREENGUARD Gold Certified

Panel Sizes - Swing-Down, Echelon™ System

48" x 6"	48" x 24"	48" x 42"	48" x 48"
48" x 54"	48" x 60"	48" x 66"	48" x 72"

24" x 6"	24" x 24"	24" x 42"	24" x 48"
24" x 54"	24" x 60"	24" x 66"	24" x 72"
24" x 78"	24" x 84"	24" x 90"	24" x 96"

30" x 6"	30" x 30"	30" x 60"	30" x 72"

Panel Sizes - Lay-In

48" x 6"	48" x 24"	48" x 42"	48" x 48"
48" x 54"	48" x 60"	48" x 66"	48" x 72"
48" x 96"

24" x 6"	24" x 24"	24" x 42"	24" x 48"
24" x 54"	24" x 60"	24" x 66"	24" x 72"
24" x 78"	24" x 84"	24" x 90"	24" x 96"
24" x 120"

30" x 6"	30" x 30"	30" x 60"	30" x 72"
30" x 96"

Physical Data

Surface Finish: Non-woven
Light Reflectance: 81% (LR1) ASTM E1477
Surface Burning: Class A (ASTM E84)
Flame Spread Index < 25
Smoke Index < 50
Acoustical Ratings - NRC: 0.85 (ASTM C 423)
Acoustical Ratings - CAC: 17 w/no backer, (ASTM E1414)
Moisture Resistance: Resistant to 95% humidity in 104 temperature
Fungal Resistance: Resistant (ASTM C1338)
Weight: 0.30 lbs. per sq. ft.
Warranty: 10 year limited
ICC: Approval (ESR-2123)

Client specific colors available. Minimum order quantity - 1,000 sq. ft.
NOTE: Color image is for illustration only.
