General Information

Suspension Systems

Swing Down

Lay-In

Echelon™

Characteristics

Proprietary formaldehyde-free glass composite construction
Monolithic appearance – large format panels, semi-concealed suspension, nominal ¼" reveals
Convenient swing-down access to the plenum
Trims are engineered for fast installation of Techstyle®
Lighting and diffuser integration
Enhanced soiling resistance and clean-ability
Formaldehyde free
Class A Fire Rating, per ASTM E84
GREENGUARD Gold Certified

Panel Sizes - Swing-Down, Echelon™ System

48" x 6"	48" x 24"	48" x 42"	48" x 48"
48" x 54"	48" x 60"	48" x 66"	48" x 72"

24" x 6"	24" x 24"	24" x 42"	24" x 48"
24" x 54"	24" x 60"	24" x 66"	24" x 72"
24" x 78"	24" x 84"	24" x 90"	24" x 96"

30" x 6"	30" x 30"	30" x 60"	30" x 72"

Panel Sizes - Lay-In

48" x 6"	48" x 24"	48" x 42"	48" x 48"
48" x 54"	48" x 60"	48" x 66"	48" x 72"
48" x 96"

24" x 6"	24" x 24"	24" x 42"	24" x 48"
24" x 54"	24" x 60"	24" x 66"	24" x 72"
24" x 78"	24" x 84"	24" x 90"	24" x 96"
24" x 120"

30" x 6"	30" x 30"	30" x 60"	30" x 72"
30" x 96"

Physical Data

Surface Finish: Non-woven
Light Reflectance: 81% (LR1) ASTM E1477
Surface Burning: Class A (ASTM E84)
Flame Spread Index < 25
Smoke Index < 50
Acoustical Ratings - NRC: 0.85 (ASTM C 423)
Acoustical Ratings - CAC: 17 w/no backer, (ASTM E1414)
Moisture Resistance: Resistant to 95% humidity in 104 temperature
Fungal Resistance: Resistant (ASTM C1338)
Weight: 0.30 lbs. per sq. ft.
Warranty: 10 year limited
ICC: Approval (ESR-2123)

Amber Oak - Wood

LIGHT GRAY

MEDIUM BROWN

NATURAL

OFF WHITE

WARM DARK BROWN

72014.4.1001

72014.4.1003

72014.4.1008

American Cherry - Wood

LIGHT GRAY

MEDIUM BROWN

NATURAL

OFF WHITE

WARM DARK BROWN

71836.4.1007

71836.4.1009

71836.4.1019

Faux Bois - Wood

LIGHT GRAY

MEDIUM BROWN

NATURAL

OFF WHITE

WARM DARK BROWN

Hard Rock Maple - Wood

LIGHT GRAY

MEDIUM BROWN

NATURAL

OFF WHITE

WARM DARK BROWN

Hudson Pine - Wood

LIGHT GRAY

MEDIUM BROWN

NATURAL

OFF WHITE

WARM DARK BROWN

71660.4.1002

71660.4.1003

71660.4.1004

71660.4.1005

Montreux Oak - Wood

LIGHT GRAY

MEDIUM BROWN

NATURAL

OFF WHITE

WARM DARK BROWN

71662.4.1002

71662.4.1003

71662.4.1004

Oakwood - Wood

LIGHT GRAY

MEDIUM BROWN

NATURAL

OFF WHITE

WARM DARK BROWN

Odenwald Walnut - Wood

LIGHT GRAY

MEDIUM BROWN

NATURAL

OFF WHITE

WARM DARK BROWN

72015.4.1002

72015.4.1004

72015.4.1009

Olmo Rigato - Wood

LIGHT GRAY

MEDIUM BROWN

NATURAL

OFF WHITE

WARM DARK BROWN

71849.4.1003

71849.4.1005

71849.4.1014

Woodrow - Wood

LIGHT GRAY

MEDIUM BROWN

NATURAL

OFF WHITE

WARM DARK BROWN

55038.3201

55038.3202

55038.3203

55038.3204

55038.3205

55038.3206

Overview

Hunter Douglas utilizes metal, wood and fiberglass materials to design, engineer and manufacture ceiling systems that optimize interior environmental quality, material resources and energy usage. Hunter Douglas incorporates sustainable materials and employs sustainable practices in our manufacturing processes. When applied as part of an overall building plan for new and renovation construction, solutions from Hunter Douglas may contribute to LEED BD+C and ID+C certification for schools, retail, hospitality, healthcare and commercial interiors.

SmartBIM ecoScorecard

Our ecoScorecard LEED calculator helps customers search and evaluate the impact of Hunter Douglas' ceilings products against leading environmental rating systems. Using the most up-to-date data in the marketplace, ecoScorecard provides clear, concise product information as well as supporting documentation.

Indoor Environmental Quality

Hunter Douglas is committed to meeting the growing demand for healthier, more sustainable products. Meeting the rigorous and comprehensive standards for low emissions of VOC's, our Greenguard Gold Certified ceilings contribute to the overall indoor air quality and general health of a building space.

The lightest, most acoustical wood look.
